Product Details
| DESCRIPTION The LTM?8046 is an isolated flyback DC/DC μModule? (micromodule) converter. The LTM8046 has an isolation rating of 2kVAC. Included in the package are the switching controller, power switches, transformer, and all support components. Operatingoveraninputvoltagerangeof3.1V to 31V, the LTM8046 supports an output voltage range of 1.8V to 12V, set by one resistor. Only output, input, and bias capacitors are needed to finish the design. An optional capacitor can be used to set the soft-start period. FEATURES ■ 2kVAC Isolated μModule Converter (Tested to 3kVDC) ■ UL 60950 Recognized ? , File E464570 ■ Wide Input Voltage Range: 3.1V to 31V ■ 5V at 550mA from 24VIN ■ 1.8V to 12V Output Voltage ■ Current Mode Control ■ Programmable Soft-Start ■ User Configurable Undervoltage Lockout ■ SnPb or RoHS Compliant Finish ■ 9mm × 15mm × 4.92mm BGA Package APPLICATIONS ■ Industrial Sensors ■ Industrial Switches ■ Ground Loop Mitigation |
Product Description
| Type | Description |
| ANSC PART# | ANSC - LTM8026IV#PBF |
| Category | Power Supplies - Board Mount |
| DC DC Converters | |
| Mfr | Original |
| Series | μModule? |
| Packaging | Tray |
| Part Status | Active |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 6V |
| Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 1.2 ~ 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Current - Output (Max) | 5A |
| Applications | ITE (Commercial) |
| Features | OTP, OVP, SCP |
| Operating Temperature | -40°C ~ 125°C |
| Efficiency | - |
| Mounting Type | Surface Mount |
| Package / Case | 81-BLGA Module |
| Size / Dimension | 0.59" L x 0.44" W x 0.11" H (15.0mm x 11.3mm x 2.8mm) |
| Supplier Device Package | 81-LGA (15x11.25) |
| Base Product Number | LTM8026 |
