Product Details
|
DESCRIPTION The LTC?5567 is optimized for RF downconverting mixer applications that require wide IF bandwidth. The part is also a pin-compatible upgrade to the LT5557 active mixer, offering higher linearity and 1dB compression, wider bandwidth, and lower output spurious levels. Integrated RF and LO transformers and LO buffer amplifiers allow a very compact solution. FEATURES ■ High IIP3: +26.9dBm at 1950MHz ■ 1.9dB Conversion Gain ■ Low Noise Figure: 11.8dB at 1950MHz ■ 16.5dB NF Under 5dBm Blocking ■ Low Power: 294mW ■ Wide IF Frequency Range Up to 2.5GHz ■ LO Input 50Ω Matched when Shutdown ■ –40°C to 105°C Operation (TC) ■ Very Small Solution Size ■ Pin Compatible with LT5557 ■ 16-Lead (4mm × 4mm) QFN package APPLICATIONS ■ Wireless Infrastructure Receivers ■ DPD Observation Receivers ■ CATV Infrastructure |
Product Description
| TYPE | DESCRIPTION |
| ANSC PART# | ANSC- LT5538IDD#PBF |
| Category | RF and Wireless |
| RF Detectors | |
| Manufacturer | Original |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Frequency | 40MHz ~ 3.8GHz |
| RF Type | General Purpose |
| Input Range | -75dBm ~ 10dBm |
| Accuracy | ±1dB |
| Voltage - Supply | 3V ~ 5.25V |
| Current - Supply | 36 mA |
| Mounting Type | Surface Mount |
| Package / Case | 8-WFDFN Exposed Pad |
| Supplier Device Package | 8-DFN (3x3) |
| Base Product Number | LT5538 |
