GENERAL DESCRIPTION The AD7904/AD7914/AD7924 are, respectively, 8-bit, 10-bit, and 12-bit, high speed, low power, 4-channel successive approximation ADCs. The parts operate from a single 2.7 V to 5.25 V power supply and feature throughput rates up to 1 MSPS. The parts contain a low noise, wide bandwidth track-and-hold amplifier that can handle input frequencies in excess of 8 MHz. FEATURES Fast throughput rate: 1 MSPS Specified for AVDD of 2.7 V to 5.25 V Low power: 6 mW maximum at 1 MSPS with 3 V supplies 13.5 mW maximum at 1 MSPS with 5 V supplies 4 single-ended inputs with sequencer Wide input bandwidth AD7924, 70 dB SNR at 50 kHz input frequency Flexible power/serial clock speed management No pipeline delays High speed serial interface: SPI/QSPI?/ MICROWIRE?/DSP compatible Shutdown mode: 0.5 μA maximum 16-lead TSSOP package Qualified for automotive applications |
Product Description
| Type | Description |
| ANSC PART# | ANSC - AD7904BRUZ |
| Category | Integrated Circuits (ICs) |
| Data Acquisition | |
| Analog to Digital Converters (ADC) | |
| Manufacturer | Original |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 8 |
| Sampling Rate (Per Second) | 1M |
| Number of Inputs | 4 |
| Input Type | Single Ended |
| Data Interface | SPI, DSP |
| Configuration | MUX-S/H-ADC |
| Ratio - S/H:ADC | 1:01 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 2.7V ~ 5.25V |
| Voltage - Supply, Digital | 2.7V ~ 5.25V |
| Features | - |
| Operating Temperature |
-40°C ~ 85°C |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
| Mounting Type | Surface Mount |
| Base Product Number | AD7904 |
