roduct Description

Product Attribute	Attribute Value
ANSC PART#	ANSC - LM311N
Manufacturer:	Texas Instruments
Product Category:	Analog Comparators
RoHS:	N
Mounting Style:	Through Hole
Package / Case:	PDIP-8
Number of Channels:	1 Channel
Output Type:	Open Collector
Response Time:	200 ns
Comparator Type:	General Purpose
Supply Voltage - Min:	5 V
Supply Voltage - Max:	36 V
Operating Supply Current:	7.5 mA
Vos - Input Offset Voltage:	7.5 mV
Ib - Input Bias Current:	250 nA
Minimum Operating Temperature:	0 C
Maximum Operating Temperature:	+ 70 C
Series:	LM311-N
Packaging:	Tube
Brand:	Texas Instruments
Dual Supply Voltage:	+/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
Features:	Strobe, Vos Adj Pin
GBP - Gain Bandwidth Product:	-
Height:	3.3 mm
Input Type:	Differential
Ios - Input Offset Current:	50 nA
Length:	9.27 mm
Maximum Dual Supply Voltage:	+/- 18 V
Minimum Dual Supply Voltage:	+/- 2.5 V
Operating Supply Voltage:	9 V, 12 V, 15 V, 18 V, 24 V, 28 V
Pd - Power Dissipation:	500 mW (1/2 W)
Product:	Analog Comparators
Product Type:	Analog Comparators
Shutdown:	Shutdown
Factory Pack Quantity:	40
Subcategory:	Amplifier ICs
Supply Type:	Single, Dual
Technology:	Bipolar
Type:	Voltage Comparator
Voltage Gain dB:	106.02 dB
Width:	6.35 mm

For more information, please download
