Car mounted 20W high-power mobile phone wireless charging single coil transmitter module DIY modification of car central control
Product Feature:
Compliant with WPC V1.2.3 wireless charging specifications
Product standard: EPP certification standard
Support wireless charging for mainstream smartphones such as Huawei, Xiaomi, Samsung, Apple, etc
Using high-performance control chips, power management chips, and low-temperature throughout the entire process
Both small cars and trucks can be used directly without the need for a voltage regulator module
High stability, strong compatibility, wide charging range
Input voltage/current: 9V-30V-2A
Output power: 20W/15/10W/7.5W/5W Automatic recognition
Charging efficiency: around 80%
Sensing distance: ≤ 8mm
Working frequency: 100-200Khz
Equipped with quadruple protection functions such as overcurrent, overvoltage, overtemperature, and short circuit
Support dual foreign object detection (FOD)
PCBA board size: length 100mm * width 50mm * thickness 11mm
Magnetic separator coil size: length 95mm * width 53mm * thickness 3.8mm
