Product Details
controllers feature a trimmed oscillator for precise duty cycle control, a temperature compensated reference, high gain error amplifier, current sensing comparator, and a high
current totem pole output ideally suited for driving a power MOSFET.
The UCX842A has UYLO thresholds of 16 V (on) and 10 V (off), ideally suited for off–line converters. The UCX843A is tailored for lower voltage applications having UVLO thresholds of 8.5 V (on) and 7.6 V (off).
? Trimmed Oscillator Discharge Current for Precise Duty Cycle Control
? Current Mode Operation to 500 kHz
? Automatic Feed Forward Compensation
? Latching PWM for Cycle–By–Cycle Current Limiting
? Internally Trimmed Reference with Undervoltage Lockout
? High Current Totem Pole Output
? Undervoltage Lockout with Hysteresis
? Low Startup and Operating Current
? Direct Interface with Motorola SENSEFET Products
Product Description
| Type | Description |
| ANSC PART# | ANSC - UC2842AN |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| DC DC Switching Controllers | |
| Manufacturer | TI |
| Series | UCx84xA |
| Packaging | Tube |
| Part Status | Active |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP |
| Base Product Number | UC2842 |
Product Photos
Product datasheet
For more information, please download
