Product Details
TPS2561ADRCT Overview
A Tape & Reel (TR) is used to package it.In the 10-VFDFN Exposed Pad package, it is included.The LED driver is mounted as Surface Mount.General Purpose is the switch type it owns.To ensure reliable operation, set the temperature to -40°C~125°C TJ.As a default, the output is set to 2.A voltage of Not Required is used to power it.There is a maximum output voltage of N-Channel volts on this LED driver.A lighting driver with Slew Rate Controlled, Status Flag features is available.It is a member of the TPS2561 family.In total, there are 10 terminations.The operation is carried out using the 10 pins.As far as the lighting driver is concerned, there are 1 functions.The maximum output current is reduced to 2.5A to meet the operation criteria.Using a voltage of 5V allows for high efficiency.The LED driving board is equipped with a total of 10 pins.This case has the output current set to 2.5A.To choose from, there are 1 channels.A maximum input voltage of 6.5V volts can be applied to it.There is a minimum input voltage of 2.5V volts.It operates at a maximum current of 125μA.For this electrical component, General Purpose is the classification.
TPS2561ADRCT Features
Supplied from 5V
1 channels
TPS2561ADRCT Applications
There are a lot of Texas Instruments
TPS2561ADRCT Power Switches ICs applications.
Set-top-box
USB Power Distribution
Notebook PC
Telecom and Network Systems
PC Card Hot Swap
Storage Drives
Portable/Handheld Devices
Wireless/Networking Cards
Low Voltage I/O System Power
Hard Disk Drives
Product Description
ANSC PART# | ANSC- TPS2561ADRCT |
Part# | TPS2561ADRCT |
Type： | Integrated Circuits |
Manufactor | Original |
DC | new |
Actual image of the product
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Power Management (PMIC) Power Distribution Switches, Load Drivers |
Mfr | Texas Instruments |
Series | - |
Packaging | Tape & Reel (TR) Cut Tape (CT) |
Part Status | Active |
Switch Type | General Purpose |
Number of Outputs | 2 |
Ratio - Input:Output | 1:2 |
Output Configuration | High Side |
Output Type | N-Channel |
Interface | On/Off |
Voltage - Load | 2.5V ~ 6.5V |
Voltage - Supply (Vcc/Vdd) | Not Required |
Current - Output (Max) | 2.5A |
Rds On (Typ) | 44mOhm |
Input Type | Non-Inverting |
Features | Slew Rate Controlled, Status Flag |
Fault Protection | Current Limiting (Adjustable), Over Temperature, UVLO |
Operating Temperature | -40°C ~ 125°C (TJ) |
Mounting Type | Surface Mount |
Supplier Device Package | 10-VSON (3x3) |
Package / Case | 10-VFDFN Exposed Pad |
Base Product Number | TPS2561 |
Product datasheet
For more information, please download
​
