Product Details
| General Description The THC63LVD823 transmitter is designed to support Single Link transmission between Host and Flat Panel Display up to SXGA+ resolutions and Dual Link transmission between Host and Flat Panel Display up to UXGA resolutions. Features ? Wide dot clock range: 25-135MHz suited for VGA, SVGA, XGA, SXGA, SXGA+ and UXGA ? PLL requires No external components ? Supports Dual Link, Dual-in (TTL)/Dual-out (LVDS) pixel up to 170MHz dot clock for UXGA ? Supports Single Link, Dual-in (TTL)/Single-out (LVDS) pixel up to 135MHz dot clock for SXGA+ ? Supports Single Link, Single-in (TTL)/Single-out (LVDS) pixel up to 85MHz dot clock for XGA ? Clock edge selectable ? Supports Reduced swing LVDS for Low EMI ? Power down mode ? Low power single 3.3V CMOS design ? 100pin TQFP ? THC63LVDM83R compatible |
Product Description
| Type# | Description |
| ANSC PART# | ANSC- THC63LVD827 |
| Ihs Manufacturer | Original |
| Package Description | TFBGA-72 |
| Differential Output | YES |
| Driver Number of Bits | 8 |
| High Level Input Current-Max | 0.00001 A |
| Input Characteristics | STANDARD |
| Interface IC Type | LINE DRIVER |
| Interface Standard | GENERAL PURPOSE |
| JESD-30 Code | S-PBGA-B72 |
| Length | 7 mm |
| Number of Functions | 8 |
| Number of Terminals | 72 |
| Operating Temperature-Max | 85 °C |
| Operating Temperature-Min | -40 °C |
| Out Swing-Min | 0.14 V |
| Output Characteristics | DIFFERENTIAL |
| Output Polarity | COMPLEMENTARY |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | TFBGA |
| Package Equivalence Code | BGA72,9X9,25 |
| Package Shape | SQUARE |
| Package Style | GRID ARRAY, THIN PROFILE, FINE PITCH |
| Seated Height-Max | 1.2 mm |
| Supply Current-Max | 88 mA |
| Supply Voltage-Max | 1.98 V |
| Supply Voltage-Min | 1.62 V |
| Supply Voltage-Nom | 1.8 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Form | BALL |
| Terminal Pitch | 0.65 mm |
| Terminal Position | BOTTOM |
| Width | 7 mm |
