SN74LS122N Overview
A 14-DIP (0.300, 7.62mm) case holds the product.Pack the equipment in case of Tube.Multivibrator is recommended to mount Multivibrator on a Through Hole-axis.The part's logic type includes Monostable.We supply it within 4.75V~5.25V.This electrical component is included in the 74LS series.A minimum operating temperature of 0°C~70°C must not be reached by this part.Despite the high voltage output, 400μA 8mA outputs a low current.Based on the 74LS122 family, the component is designed.There are a total of 14 terminations.5V voltage can be handled by it.Data or clock inputs are available on 4 inputs.14 pins are present on the part in total.There is a LS family member.The part includes 14 pins.By mounting the device, Through Hole provides a secure connection.There is a quiescent current consumption at 6mA.5V volts is the operating supply voltage for the chip.Input current to the device is 8mA.Integrated circuit can provide voltage up to 5V volts.2 is the total number of bits on an IC chip.Additional features of the part can be found by searching: RETRIGGERABLE; TRIGGERABLE FROM CLEAR INPUT ALSOA 1 element is present in it.
SN74LS122N Features
in 14-DIP (0.300, 7.62mm) package
Mounting Type: Through Hole
Logic Type: Monostable
Operating Temperature: 74LS
based on 74LS122
Supply Voltage: 5V
Quiescent Current at 6mA
output current at 8mA
2 bits
SN74LS122N Applications
There are a lot of Texas Instruments
SN74LS122N applications of multivibrators.
Pulse shaping
Astable multivibrator
Envelope detection
Frequency multiplication
Frequency division
Frequency discriminators
Timing clrcults
Time-delay applications
AV Receivers
Blu-ray Players and Home Theaters
Product Description
ANSC PART# | ANSC- SN74LS122N |
Part# | SN74LS122N |
Type： | Integrated Circuits |
Manufactor | Original |
DC | new |
Actual image of the product
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Logic Multivibrators |
Manufacturer | Texas Instruments |
Series | 74LS |
Packaging | Tube |
Part Status | Active |
Logic Type | Monostable |
Independent Circuits | 1 |
Schmitt Trigger Input | No |
Propagation Delay | 28 ns |
Current - Output High, Low | 400μA, 8mA |
Voltage - Supply | 4.75 V ~ 5.25 V |
Operating Temperature | 0°C ~ 70°C |
Mounting Type | Through Hole |
Package / Case | 14-DIP (0.300", 7.62mm) |
Supplier Device Package | 14-PDIP |
Base Product Number | 74LS122 |
