SNJ54LVCH244AW Overview
High reliability is ensured by the advanced packaging method Rail/Tube. There are several in the * series. Many applications include this logic device with a Surface Mount mounting. For details about the functions of 20 pins, please refer to the datasheets. A 8 input is supported by the part. The current flowing through quiet parts is 10 μA. In this device, there are 8 outputs. Operation is based on 2 elements in total. In environments with temperatures above 125 °C, the device should be avoided. Test statistics indicate that the part would operate at -55 °C degrees Celsius. normally, users should not supply the device with voltage higher than 3.6 V. It is recommended to use 2 V as the lowest voltage for the part. It provides high-quality logic output, thanks to its 8 channels. It is capable of carrying out 8-bit operation.
SNJ54LVCH244AW Features
Quiescent Current: 10 μA
SNJ54LVCH244AW Applications
There are a lot of Texas Instruments
SNJ54LVCH244AW Gates and Inverters applications.
Washing machine
Range hood
Refrigerator
VCR
Massager
Fan
Illumination
Cell phone
Laptop
Digital camera
Product Description
ANSC PART# | ANSC- SNJ54LVCH244AW |
Part# | SNJ54LVCH244AW |
Type： | Integrated Circuits |
Manufactor | Original |
DC | new |
Actual image of the product
| Product Attribute | Attribute Value |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | Buffers & Line Drivers |
| Logic Family: | LVC |
| Number of Input Lines: | 8 Input |
| Number of Output Lines: | 8 Output |
| Polarity: | Non-Inverting |
| Package / Case: | CFP-20 |
| High Level Output Current: | - 24 mA |
| Low Level Output Current: | 24 mA |
| Quiescent Current: | 10 uA |
| Supply Voltage - Min: | 2 V |
| Supply Voltage - Max: | 3.6 V |
| Minimum Operating Temperature: | - 55 C |
| Maximum Operating Temperature: | + 125 C |
| Mounting Style: | SMD/SMT |
| Packaging: | Tube |
| Brand: | Texas Instruments |
| Function: | Buffer/Line Driver |
| Height: | 1.84 mm |
| Input Signal Type: | Single-Ended |
| Length: | 13.09 mm |
| Logic Type: | CMOS |
| Number of Channels: | 8 |
| Operating Supply Voltage: | 2 V to 3.6 V |
| Output Type: | 3-State |
| Product Type: | Buffers & Line Drivers |
| Propagation Delay Time: | 7.5 ns at 2.7 V, 6.5 ns at 3.3 V |
| Series: | SN54LVCH244A |
| Factory Pack Quantity: | 1 |
| Subcategory: | Logic ICs |
| Supply Current - Max: | 10 uA |
| Technology: | CMOS |
| Width: | 6.92 mm |
