CD4052BF Overview
In order to save board space, digital switch is located in the 16-CDIP (0.300, 7.62mm).Rail/Tube is the packaging method.Digital switch ic uses a Through Hole mounting method.the multiplexers uses an analog IC Analog Multiplexer.When the operating temperature is kept at -55°C ~ 125°C (TA), turn signal switch will not be susceptible to external factors.Multiplexers of the - series can be used in a wide range of applications.This turn signal switch has 16 component pins.As the end of conductors, it uses THROUGH-HOLE.In order to prevent unnecessary failures, it is recommended that the minimal supply voltage (Vsup) be kept at 3 V.It is advisable to keep the maximum supply voltage (Vsup) at 20 V so as to avoid some unnecessary failures.mux switch's normal operation requires the power supply of 5/15 V.The turn signal switch has 2 outputs.Multiplexer or Switches is the classification for this the digital switch ic.This multiplexer has 8 inputs.The turn signal switch's circuit has 2 transmission channels.During normal operation, the digitalswitch consists of 2 circuits.DIFFERENTIAL MULTIPLEXER is its analog integrated circuit.
CD4052BF Features
Supplied in the 16-CDIP (0.300, 7.62mm) package
Power supplies of 5/15 V
DIFFERENTIAL MULTIPLEXER as the analog IC
CD4052BF Applications
There are a lot of Texas Instruments
CD4052BF Signal Switches / Multiplexers / Decoders applications.
Telephone network
Computer memory
Transmission from the computer system of a satellite
Time division multiplexing system
Frequency multiplexing system
A/D converters
D/A converters
Implementing boolean functions with multiple variables
Data collection system
Audio transmission
Product Description
ANSC PART# | ANSC- CD4052BF |
Part# | CD4052BF |
Type： | Integrated Circuits |
Manufactor | Texas Instruments |
DC | new |
Actual image of the product
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Interface Analog Switches, Multiplexers, Demultiplexers |
Manufacturer | Texas Instruments |
Series | - |
Packaging | Tube |
Part Status | Active |
Switch Circuit | DP4T |
Multiplexer/Demultiplexer Circuit | 4:1 |
Number of Circuits | 2 |
On-State Resistance (Max) | 240Ohm |
Channel-to-Channel Matching (ΔRon) | 5Ohm |
Voltage - Supply, Single (V+) | 3V ~ 20V |
Voltage - Supply, Dual (V±) | - |
Switch Time (Ton, Toff) (Max) | - |
-3db Bandwidth | 25MHz |
Charge Injection | - |
Channel Capacitance (CS(off), CD(off)) | 0.2pF, 18pF |
Current - Leakage (IS(off)) (Max) | 100nA |
Crosstalk | -40dB @ 10MHz |
Operating Temperature | -55°C ~ 125°C (TA) |
Mounting Type | Through Hole |
Package / Case | 16-CDIP (0.300", 7.62mm) |
Supplier Device Package | 16-CDIP |
