Product Details
|
The ADC080X family are CMOS 8-Bit, successive approximation A/D converters which use a modified potentiometric ladder and are designed to operate with the 8080A control bus via three-state outputs. These converters appear to the processor as memory locations or I/O ports, and hence no interfacing logic is required. Features ? 80C48 and 80C80/85 Bus Compatible - No Interfacing Logic Required ? Conversion Time . . . . . . . . . . . . . . . . . . . . . . . . . . <100μs ? Easy Interface to Most Microprocessors ? Will Operate in a “Stand Alone” Mode ? Differential Analog Voltage Inputs ? Works with Bandgap Voltage References ? TTL Compatible Inputs and Outputs ? On-Chip Clock Generator ? Analog Voltage Input Range (Single + 5V Supply) . . . . . . . . . . . . . . . . . . . . . . 0V to 5V ? No Zero-Adjust Required ? 80C48 and 80C80/85 Bus Compatible - No Interfacing Logic Required |
Product Description
| Type | Description |
| ANSC PART# | ANSC - ADC0804LCN |
| Category | Integrated Circuits (ICs) |
| Data Acquisition | |
| Analog to Digital Converters (ADC) | |
| Manufacturer | Original |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Number of Bits | 8 |
| Sampling Rate (Per Second) | 10k |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | Parallel |
| Configuration | ADC |
| Ratio - S/H:ADC | - |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Supply |
| Voltage - Supply, Analog | 4.5V ~ 6.3V |
| Voltage - Supply, Digital | 4.5V ~ 6.3V |
| Features | - |
| Operating Temperature |
0°C ~ 70°C |
| Package / Case | 20-DIP (0.300", 7.62mm) |
| Supplier Device Package | 20-PDIP |
| Mounting Type | Through Hole |
| Base Product Number | ADC0804 |
