Product Details
|
DESCRIPTION The 74V2G00 is an advanced high-speed CMOS DUAL 2-INPUT NAND GATE fabricated with sub-micron silicon gate and double-layer metal wiring C2MOS technology. ■ HIGH SPEED: tPD = 3.7 ns (TYP.) at VCC = 5V ■ LOW POWER DISSIPATION: ICC =1 μA (MAX.) at TA = 25 °C ■ HIGH NOISE IMMUNITY: VNIH = VNIL = 28% VCC (MIN.) ■ POWERDOWN PROTECTIONON INPUTS AND OUTPUTS ■ SYMMETRICAL OUTPUT IMPEDANCE: |IOH| = IOL = 8 mA (MIN) ■ BALANCEDPROPAGATIONDELAYS: tPLH ? tPHL ■ OPERATING VOLTAGERANGE: VCC (OPR)= 2V to 5.5V ■ IMPROVED LATCH-UP IMMUNITY |
Product Description
| Type | Description |
| ANSC PART# | ANSC - 74V2G00STR |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Gates and Inverters | |
| Mfr | STMicroelectronics |
| Series | 74V |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Logic Type | NAND Gate |
| Number of Circuits | 2 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 2V ~ 5.5V |
| Current - Quiescent (Max) | 2 μA |
| Current - Output High, Low | 8mA, 8mA |
| Input Logic Level - Low | 0.5V |
| Input Logic Level - High | 1.5V |
| Max Propagation Delay @ V, Max CL | 7.5ns @ 5V, 50pF |
| Operating Temperature |
-55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23-8 |
| Package / Case | SOT-23-8 |
| Base Product Number | 74V2G00 |
