Product Details
| DESCRIPTION The LT1161 is a quad high-side gate driver allowing the use of low cost N-channel power MOSFETs for high-side switching applications. It has four independent switch channels, each containing a completely self-contained charge pump to fully enhance an N-channel MOSFET switch with no external components. ■ 8V to 48V Power Supply Range ■ Protected from –15V to 60V Supply Transients ■ Fully Enhances N-Channel MOSFET Switches ■ Individual Short-Circuit Protection ■ Individual Automatic Restart Timers ■ Programmable Current Limit, Delay Time, and Auto-Restart Period ■ Voltage-Limited Gate Drive ■ Defaults to OFF State with Open Input ■ Flowthrough Input to Output Pinout ■ Available in 20-Lead DIP or SOL Package ■ Industrial Control ■ Avionics Systems ■ Automotive Switches ■ Stepper Motor and DC Motor Control ■ Electronic Circuit Breaker |
Product Description
| Type | Description |
| ANSC PART# | ANSC - LT1161ISW |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Gate Drivers | |
| Manufacturer | Original |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| DigiKey Programmable | Not Verified |
| Driven Configuration | High-Side |
| Channel Type | Independent |
| Number of Drivers | 4 |
| Gate Type | MOSFET (N-Channel) |
| Voltage - Supply | 8V ~ 48V |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| Current - Peak Output (Source, Sink) | - |
| Input Type | Non-Inverting |
| Rise / Fall Time (Typ) | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SO |
| Base Product Number | LT1161 |
