Product Description
74AHC1G00 and 74AHCT1G00 are high-speed Si-gate CMOS devices. They provide a 2-input NAND function.
The AHC device has CMOS input switching levels and supply voltage range 2 V to 5.5 V.
The AHCT device has TTL input switching levels and supply voltage range 4.5 V to 5.5 V.
Product Features
? Symmetrical output impedance
? High noise immunity
? Low power dissipation
? Balanced propagation delays
? SOT353-1 and SOT753 package options
? ESD protection:
? HBM JESD22-A114E: exceeds 2000 V
? MM JESD22-A115-A: exceeds 200 V
? CDM JESD22-C101C: exceeds 1000 V
? Specified from -40°C ~ 125°C
Specifications
| Attribute | Attribute value |
| ANSM-Part# | ANSM-74AHCT1G00GV |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Gates and Inverters | |
| Mfr | NXP USA Inc. |
| Series | 74AHCT |
| Package | Bulk |
| Product Status | Active |
| Logic Type | NAND Gate |
| Number of Circuits | 1 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | 1 μA |
| Current - Output High, Low | 8mA, 8mA |
| Input Logic Level - Low | 0.8V |
| Input Logic Level - High | 2V |
| Max Propagation Delay @ V, Max CL | 7.9ns @ 5V, 50pF |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 5-TSOP |
| Package / Case | SC-74A, SOT-753 |
| Base Product Number | 74AHCT1G00 |
