Product Applications
? TI MSP430 Attach Applications
? Wireless Handsets and Smart Phones
? MP3 Players
? Battery-Operated Handheld Products
Product Features
? Low IQ: 500 nA
? 150-mA, Low-Dropout Regulator
? Input Voltage Range: 2.2 V to 5.5 V
? Low-Dropout at 25°C, 130 mV at 150 mA
? Low-Dropout at 85°C, 175 mV at 150 mA
? 3 PERCENT Accuracy Over Load, Line, and Temperature
? Stable with a 1.0-μF Ceramic Capacitor
? Thermal Shutdown and Overcurrent Protection
? CMOS Logic Level-Compatible Enable Pin
? Available in DDC (TSOT23-5) or DRV (2-mm x 2-mm SON-6) Packages
Specifications
| Attribute | Attribute value |
| ANSM-Part# | ANSM-TPS78228DDCT |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Regulators - Linear, Low Drop Out (LDO) Regulators | |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel? | |
| Product Status | Active |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 2.8V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.25V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 1.3 μA |
| Current - Supply (Max) | 8 μA |
| PSRR | 40dB ~ 15dB (10Hz ~ 1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-5 Thin, TSOT-23-5 |
| Supplier Device Package | SOT-23-THIN |
| Base Product Number | TPS78228 |
