Product Descriptions
The LM2936 ultra-low quiescent current regulatorfeatures low dropout voltage and low current in thestandby mode. With less than 15 uA quiescentcurrent at a 100 A load, the LM2936 is ideally suitedfor automotive and other battery operated systems.The LM2936 retains all of the features that arecommon to low dropout regulators including a lowdropout PNP pass device, short circuit protection,reverse battery protection, and thermal shutdown.The LM2936 has a 40V maximum operating voltagelimit，a -40°C to +125C operating temperaturerange and +3% output voltage tolerance over theentire output current, input voltage, and temperaturerange. The LM2936 is available in a TO-92 package.SOIC-8 and SOT-223 surface mount packages, anda PFM surface mount power package
Specifications
| Attribute | Attribute value |
| ANSM-Part# | ANSM-LM2936BM-5.0 |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Regulators - Linear, Low Drop Out (LDO) Regulators | |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tube |
| Product Status | Obsolete |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 40V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.4V @ 50mA |
| Current - Output | 50mA |
| Current - Quiescent (Iq) | 9 μA |
| Current - Supply (Max) | 2.5 mA |
| PSRR | 60dB (120Hz) |
| Control Features | Shutdown |
| Protection Features | Over Temperature, Reverse Polarity, Short Circuit |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | LM2936 |
