Product Details
The LPC1763 is a Cortex?-M3 microcontroller for embedded applications featuring a high-level of integration and low power consumption at frequencies of 100 MHz. Features include 256 kB of flash memory, 64 kB of data memory, 8-channel DMA controller, 4 UARTs, 3 SSP/SPI, 3 I2C, I2S, 8-channel 12-bit ADC, 10-bit DAC, motor control PWM, Quadrature Encoder interface, 4 general purpose timers, 6-output general purpose PWM, ultra-low power Real-Time Clock with separate battery supply, and up to 70 general purpose I/O pins. The LPC1763 is pin-compatible to the 100-pin LPC2368 Arm7? MCU
Specifications
Attribute | Attribute value |
ANSM-Part# | ANSM-LPC1763FBD100 |
Category | Integrated Circuits (ICs) |
Embedded | |
Microcontrollers | |
Mfr | NXP USA Inc. |
Series | LPC17xx |
Package | Tray |
Product Status | Active |
DigiKey Programmable | Not Verified |
Core Processor | ARM? Cortex?-M3 |
Core Size | 32-Bit Single-Core |
Speed | 100MHz |
Connectivity | I2C, IrDA, Microwire, SPI, SSI, UART/USART |
Peripherals | Brown-out Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, WDT |
Number of I/O | 70 |
Program Memory Size | 256KB (256K x 8) |
Program Memory Type | FLASH |
EEPROM Size | - |
RAM Size | 64K x 8 |
Voltage - Supply (Vcc/Vdd) | 2.4V ~ 3.6V |
Data Converters | A/D 8x12b; D/A 1x10b |
Oscillator Type | Internal |
Operating Temperature | -40°C ~ 85°C (TA) |
Mounting Type | Surface Mount |
Package / Case | 100-LQFP |
Supplier Device Package | 100-LQFP (14x14) |
Base Product Number | LPC1763 |
