Product Descriptions
The LSTTL/MSI SN54/74LS157 is a high speed Quad 2-Input Multiplexer. Four bits of data from two sources can be selected using the common Select and Enable inputs. The four buffered outputs present the selected data in the true (non-inverted) form. The LS157 can also be used to generate any four of the 16 different functions of two variables. The LS157 is fabricated with the Schottky barrier diode process for high speed and is completely compatible with all Motorola TTL families.
Product Features
? Schottky Process for High Speed
? Multifunction Capability
? Non-Inverting Outputs
? Input Clamp Diodes Limit High Speed Termination Effects
? Special Circuitry Ensures Glitch Free Multiplexing
? ESD > 3500 Volts
Specifications
| Part# | SN54LS157J |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Signal Switches, Multiplexers, Decoders | |
| Mfr | Texas Instruments |
| Series | 54LS |
| Package | Tube |
| Product Status | Active |
| Type | Data Selector/Multiplexer |
| Circuit | 4 x 2:1 |
| Independent Circuits | 1 |
| Current - Output High, Low | 400μA, 4mA |
| Voltage Supply Source | Single Supply |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 16-CDIP |
