General Description The HMC344 is a broadband non-refl ective GaAs MESFET SP4T switch chip. Covering DC to 8 GHz, this switch offers high isolation, low insertion loss, and a compact form factor. This switch also includes an on board binary decoder circuit which reduces the number of required logic control lines to two. The switch operates using a negative control voltage of 0/-5V, and requires a fi xed bias of -5V. All data is tested with the chip in a 50 Ohm test fi xture connected via 0.025 mm (1 mil) diameter wire bonds of minimal length 0.31 mm (12 mils). This SP4T switch is also available in SMT packaged form as the HMC344LC3.
Broadband Performance: DC - 8 GHz Non-Refl ective Topology Low Insertion Loss: 1.8 dB @ 6 GHz Integrated 2:4 TTL Decoder Small Size: 1.08 x 1.05 x 0.10 mm Typical Applications The HMC344 is ideal for: ? Telecom Infrastructure ? Microwave Radio & VSAT ? Military & Space ? Test Instrumentation |
Product Description
| TYPE | DESCRIPTION |
| ANSC PART# | ANSC- HMC349ALP4CE |
| Category | RF and Wireless |
| RF Switches | |
| Manufacturer | Original |
| Series | - |
| Packaging | Strip |
| Part Status | Active |
| RF Type | General Purpose |
| Topology | Absorptive |
| Circuit | SPDT |
| Frequency Range | 0Hz ~ 4GHz |
| Isolation | 62dB |
| Insertion Loss | 1.4dB |
| Test Frequency | 4GHz |
| P1dB | 34dBm |
| IIP3 | - |
| Features | - |
| Impedance | 50Ohm |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-VQFN Exposed Pad, CSP |
| Supplier Device Package | 16-LFCSP (4x4) |
| Base Product Number | HMC349 |
