Product Details
General Description
The MAX667 low-dropout, positive, linear voltage regulator supplies up to 250mA of output current. With no load, it has a typical quiescent current of 20μA. At 200mA of output current, the input/output voltage differential is typically 150mV. Other features include a low-voltage detector to indicate power failure, as well as early-warning and low-dropout detectors to indicate an imminent loss of output voltage regulation. A shutdown control disables the output and puts the circuit into a low quiescent-current mode.
Features
? 350mV Max Dropout at 200mA
? 250mA Output Current
? Normal Mode: 20μA Typ Quiescent Current
Shutdown Mode: 0.2μA Typ Quiescent Current
? Low-Battery Detector
? Fixed +5V (Min Component Count) or Adjustable Output
? +3.5V to +16.5V Input
? Dropout Detector Output
? 10μF Output Capacitor
Applications
Battery-Powered Devices
Pagers and Radio Control Receivers
Portable Instruments
Solar-Powered Instruments
Product Description
ANSC PART# | ANSC- MAX667ESA |
Part# | MAX667ESA |
Type： | Integrated Circuits |
Manufactor | Original |
DC | new |
Actual image of the product
Specifications
Series | - |
Packaging | Tube |
Package / Case | 8-SOIC (0.154", 3.90mm Width) |
Operating Temperature | -40°C ~ 85°C |
Mounting Type | Surface Mount |
Supplier Device Package | 8-SOIC |
Voltage - Input | 3.5 V ~ 16.5 V |
Current - Output | 250mA |
Voltage - Output | 5V, 1.3 V ~ 16 V |
Regulator Topology | Positive Fixed or Adjustable |
Voltage - Dropout (Typical) | 0.15V @ 250mA |
Number of Regulators | 1 Regulator |
Current - Limit (Min) | - |
Product datasheet
For more information, please download
