Product Features
? 802.11 b/g/n
? Integrated low power 32-bit MCU
? Integrated 10-bit ADC
? Integrated TCP/IP protocol stack
? Integrated TR switch, balun, LNA, power amplifier and matching network
? Integrated PLL, regulators, and power management units
? Supports antenna diversity
? Wi-Fi 2.4 GHz, support WPA/WPA2
? Support STA/AP/STA+AP operation modes
? Support Smart Link Function for both Android and iOS devices
? SDIO 2.0, (H) SPI, UART, I2C, I2S, IRDA, PWM, GPIO
? STBC, 1x1 MIMO, 2x1 MIMO
? A-MPDU & A-MSDU aggregation and 0.4s guard interval
? Deep sleep power <10uA, Power down leakage current < 5uA
? Wake up and transmit packets in < 2ms
? Standby power consumption of < 1.0mW (DTIM3)
? +20dBm output power in 802.11b mode
? Operating temperature range -40C ~ 85C
Specifications
| Attribute | Attribute value |
| ANSM-Part# | ANSM-ESP-07S |
| Category | RF and Wireless |
| RF Transceiver Modules and Modems | |
| Mfr | RF Solutions |
| Series | - |
| Package | Bag |
| Product Status | Active |
| DigiKey Programmable | Not Verified |
| RF Family/Standard | WiFi |
| Protocol | 802.11b/g/n |
| Modulation | 64-QAM, BPSK, CCK |
| Frequency | 2.4GHz ~ 2.5GHz |
| Data Rate | 54Mbps |
| Power - Output | 20dBm |
| Sensitivity | - |
| Serial Interfaces | GPIO, I2C, I2S, PWM, SDIO, SPI, UART |
| Antenna Type | PCB Trace |
| Utilized IC / Part | - |
| Memory Size | - |
| Voltage - Supply | 3V ~ 3.6V |
| Current - Receiving | - |
| Current - Transmitting | - |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | Module |
| Base Product Number | ESP-07 |
